brake cylinder with return spring and mounting set (bottom mounting) Ø30mm Ø50mm 95mm ingeschoven lengte 290 / uitgeschoven leng
FAD
Reference : 180.000.356.024
Brand FAD Industry Agriculture name brake cylinder with return spring and mounting set (bottom mounting) diameter piston rod Ø30mm diameter cylinder Ø50mm stroke 95 mm dimension ingeschoven lengte 290 / uitgeschoven lengte 385 mm force at 100 Bar in DaN 700 DaN force at 150 Bar in DaN 1059 DaN REACH-compliant yes
415,80 € incl. VAT
On order Supply lead time : environ 8 semaines
📩 Notify me when this product is available again
A single email, when it is back in stock. No spam.
Specifications
| Industry | Agriculture |
| dimension | longueur rétractée 290mm / longueur déployé 385mm mm |
| name | cylindre de frein avec ressort de rappel et kit de montage (montage inférieur) |
| stroke | 95 mm |
| diameter piston rod | Ø30mm |
| diameter cylinder | Ø50mm |
| force at 100 Bar in DaN | 700 DaN |
| force at 150 Bar in DaN | 1059 DaN |
Description
- Brand
- FAD
- Industry
- Agriculture
- name
- brake cylinder with return spring and mounting set (bottom mounting)
- diameter piston rod
- Ø30mm
- diameter cylinder
- Ø50mm
- stroke
- 95 mm
- dimension
- ingeschoven lengte 290 / uitgeschoven lengte 385 mm
- force at 100 Bar in DaN
- 700 DaN
- force at 150 Bar in DaN
- 1059 DaN
- REACH-compliant
- yes
