swivel castor with brake 200mm series 14 ᠆ 32 plate mounting ball bearing

Reference : 214.206.196.300

Brand Novio Application Transportwheels Industry Food industry and industrial kitchens Industry and internal logistics Wheel type swivel castor Wheel diameter 200 mm Fork mounting plate mounting Bearing type ball bearing Brake type double brake, front Tread material rubber / TPE Overall height 245 mm Maximum load capacity 400 kg width 48 mm rim PA rim colour silver grey RAL 7001 diameter axle bore 12 mm diameter axle bore fork 12,2 mm hub length mm 60 mm hub-to-fork length 63 mm offset 57 mm co…

On order Supply lead time : environ 8 semaines

📩 Notify me when this product is available again

Notify me

A single email, when it is back in stock. No spam.

Quantity

🛒 Add to cart

Specifications

Industry	Industrie alimentaire et restauration collective Industrie et logistique interne
Application	Roue de transport
width	48 mm
Wheel type	roulette pivotante
Bearing type	roulement à billes
Maximum load capacity	400 kg
Wheel diameter	200 mm
offset	57 mm
Tread material	caoutchouc / TPE
rim	PA
Overall height	245 mm
hub length mm	60 mm
Fork mounting	fixation platine
rim colour	gris argent RAL 7001
material fork	métal
Brake type	frein double, avant
dimension fixing	135x110 / 105x75/80 / Ø12 mm
diameter axle bore fork	12,2 mm
hub-to-fork length	63 mm
tire	caoutchouc souple
tire colour	gris argent RAL 7001
tolerance hardness	+/-3
hardness Shore A	70 Shore A
diameter axle bore	12 mm
colour support/housing	zingué
